Simple Classification with MSE Loss

I’m getting hangups in the loss when doing classification using MSE loss. I’m attempting to follow the standard setup provided in the guides but the loss continues to get stuck at 0.25 regardless of the architecture of the network, which is making me suspicious that there is an error somewhere. The same setup works fine for a single dimensional regression task, so I believe the code is working.

I’ve attached a simple example trying to classify two dimensional data using MSE Loss

## IMPORTS ##
import math
import jax.numpy as np
from jax.experimental import stax
import jax
from jax import random
from jax import grad, jit, vmap
from jax.experimental import optimizers

## LOSS FUNCTION ##

def loss(params, apply_fn, inputs, targets):
    preds = apply_fn(params, inputs)
    out = np.mean((preds - targets)**2)
    print(out)
    return out

## INIT NETWORK ##
width = 100
init, apply = stax.serial(stax.Dense(width), stax.Relu,
                          stax.Dense(width), stax.Relu,
                          stax.Dense(width), stax.Relu,
                          stax.Dense(width), stax.Relu,
                          stax.Dense(1))

## GENERATE KEYS AND DATA ##
key = random.PRNGKey(10)
gen_key1, gen_key2, key = random.split(key, 3)

def twospirals(n_points, noise=.5, random_state=920):
    """
     Returns the two spirals dataset.
    """
    n = np.sqrt(random.uniform(key,(n_points,1))) * 600 * (2*np.pi)/360
    d1x = -1.5*np.cos(n)*n + random.normal(gen_key1,(n_points,1)) * noise
    d1y =  1.5*np.sin(n)*n + random.normal(gen_key2,(n_points,1)) * noise

    return (np.vstack((np.hstack((d1x,d1y)),np.hstack((-d1x,-d1y)))),
            np.hstack((np.zeros(n_points),np.ones(n_points))))


n_train = 500
train_x, train_y = twospirals(n_train, noise=0.5)

## DRAWING PARAMETERS ##
init_key = random.PRNGKey(42)
_, params = init(init_key, (-1, 2))

## RUNNING OPTIMIZATION ##
opt_init, opt_update, get_params = optimizers.adam(step_size=0.01)

def step(i, opt_state):
    params = get_params(opt_state)
    g = grad(loss)(params, apply, train_x, train_y)
    return opt_update(i, g, opt_state)

# Optimize parameters in a loop
opt_state = opt_init(params)
for i in range(1000):
    opt_state = step(i, opt_state)

And the classifier looks like:

As mentioned above the fact that independent of model width/depth the loss does not go below 0.25 gives the sense that something is amiss. Any help would be appreciated - thanks!

[froystig]

I suspect that the predictions and the targets have different dimensions in the loss function. Let’s say N is width. The output of the Dense(1) layer is 2-dimensional, N x 1. Meanwhile, the targets that you supply are 1-dimensional, of length N. This causes targets to be broadcast within loss, but likely not in the way that you intend: preds - targets is (N, N)-shaped.

This behavior is dictated by NumPy, so the same issue would have come up in a pure NumPy implementation, without having JAX involved.

You could change the training set to produce (N, 1)-shaped targets. Alternatively, in loss, changing the line

out = np.mean((preds - targets)**2)

to

out = np.mean((preds.squeeze() - targets)**2)

should work as well.

@hawkinsp’s suggestion above likely improved matters simply because it led to 2-dimensional targets.

[sunny2309]

Hello @froystig ,

Your comment above about preds dimension being (N,1) in loss function helped me a lot. I was stuck on it for long as my MSE for simple regression task was not reducing beyond particular value. With just addition of squeeze() solved problem immediately. I had no idea that broadcasting can create such problem. I was just doing .mean() on last value without checking dimensions.

Your one comment helped me solve my problem.

Really Appreciate it.

Regards, Sunny
